Angle Steel

Angle Steel

Size range

25x25mm to 250x250mm

Thickness

3mm to 25mm

Length

6,000 / 12,000mm or cut-to-size

Steel grades

AGS400, SS400, Q235B, A36, A572, etc

Mills

Nha Be, AKS, Japan, Thailand, China, etc

Standards

JIS G3101:2015, GB/T 700-2006, JIS G3192, ASTM, etc

Look up product range

High production output

Large manufacturing capacity to efficiently fulfill bulk orders and key projects.

Competitive pricing

Offering budget-friendly yet competitive prices while maintaining product quality.

Trusted by clients

Chosen by hundreds of domestic and international clients for consistent quality and professional service.

Describe Product

Mục lục

Angle steel, commonly referred to as L-shaped steel, is a highly versatile structural product widely used across industries. It is characterized by two equal-length sides forming a 90-degree angle. This type of steel is well-known for its strength, toughness, and ease of fabrication, making it ideal for various structural and engineering applications.

I. STRUCTURAL FEATURES

Excellent load-bearing capacity: Angle steel offers excellent structural support, capable of withstanding heavy loads and harsh conditions. The L-shaped design distributes weight evenly, enhancing both strength and stability
Versatility: Angle steel can be applied across a wide range of uses—from construction structures and buildings to machinery frames and support systems. Its design enables flexible integration with other materials, meeting a wide range of structural requirements effectively. Its adaptability makes it suitable for diverse project requirements
Ease of fabrication: Angle steel is easy to process using various methods such as cutting, bending, forming, and welding, suitable for many different design needs
Cost-effective: Compared to other structural materials, angle steel offers a relatively low production cost. Its simple shape and efficient manufacturing process contribute to its affordability. Additionally, its durability helps reduce long-term maintenance expenses.
Wide range of sizes: Angle steel is available in a variety of sizes and thicknesses, making it suitable for a broad spectrum of construction and engineering applications.

	Tính chất vật lý(Mechanical Properties)			Tính chất hoá học(Chemical Composition)
Mác thép(Grade)	Độ bền chảy(Yeild Strength) (Mpa ~ N/mm2) Min	Độ bền kéo(Tensile Strength) (Mpa ~ N/mm2) Min	Độ giãn dài(Elongation) %	C%	Si%	Mn%	P%	S%
AGS400	≥ 245	400 – 510	≥ 17	≤ 0.25	≤ 0.40	≤ 1.6	≤ 0.050	≤ 0.050
SS400	≥ 245*	400 – 510	≥ 21	≤ 0.29	≤ 0.40	≤ 1.6	≤ 0.050	≤ 0.050
A36	≥ 250	400 – 550	≥ 20	≤ 0.26	≤ 0.40		≤ 0.040	≤ 0.050
Q235B	≥ 235*	375 – 500	≥ 26*	≤ 0.20	≤ 0.30	0.30 – 0.70	≤ 0.045	≤ 0.045
A572 Gr50	≥ 345	450 – 620	≥ 18	≤ 0.23	0.15 – 0.4	1.35 – 1.65	≤ 0.0 40	≤ 0.050

II. TOLERANCE

Thickness tolerance: ±0.3 – 0.6mm

Leg length tolerance: ±1.0 – 2.0mm

Weight tolerance: ±5%

Thickness tolerance: ±10mm

IIi. PACKING AND DELIVERY

Total Weight:1,500kg/bundle – 2,000kg/bundle

IV. PRACTICAL APPLICATIONS

Construction and structural applications: L-shaped steel is commonly used in the construction of factories, industrial buildings, and steel structures such as beams and roof frames
Bridges and infrastructure: This type of steel is also used in the construction of ports and bridges due to its high load-bearing capacity and excellent corrosion resistance
Mechanical engineering and manufacturing: L-shaped steel is used in the fabrication of machine components, tank frames, and in the automotive manufacturing industry
Furniture and household applications: Additionally, L-shaped steel is used in the production of furniture and household products, thanks to its durability, structural integrity, and ease of fabrication.
